Mine Media Stream Decoder

$445.00

4K 24/7 Stream Decoder

Stable and reliable, 24x7 operating time.
Web Control UI, default IP is 192.168.1.169.
Support SRT /HTTP / HLS / FLV / RTSP / RTMP(S) / UDP/RTP (Unicast/Multicast) streaming decoding.
Support output resolution - 3840×2160@30fps, 1080P/1080I/720P@60FPS, etc.
Support Text and image insert as OSD output.
Direct RTMP capable, no need for a CDN in the middle.
Takes Web Conference RTMP and output to TV, Encoder, etc. by port forwarding

Add to Cart

Product Details

Specifications

This IP Video Decoder can receive the SRT / HTTP / HLS / FLV / RTSP / RTMP(S) / UDP/RTP (Unicast/Multicast) stream from our HDMI/VGA/SDI encoder or media streaming server, by H.265/H.264 video & audio decoding, then output HDMI, SDI, VGA, CVBS and L/R stereo audio. Its high integration and cost-effective design make this device widely used in variety of field such as advertisement display, CCTV, long distance video transfer, etc.

MineMedia Decoder Specifications

Interfaces
---
HDMI Output
3840*2160P@30/1440P@30/1080P@60/1080I@60/1080P@50/1080I@50;
&
1080P30/1080P25/720P60/720P50/576P50/480P60 fps
SDI Output
1080P@60/1080I@60/1080P@50/1080I@50; 1080P30/1080P25/720P60/720P50
VGA Output
1080P@60/1080I@60/1080P@50/1080I@50; 1080P30/1080P25/720P60/720P50/576P50/480P60 fps
CVBS Output
PAL 720*576 & NTSC 720*480
Audio Output
HDMI /SDI embed audio & External Analog audio
Ethernet
1000Mbps, RJ-45
WiFi
Option – 2.4G
Video Decoding
---
Video Format
H.264/AVC High/Main/Baseline Profile H.265/HEVC main profile MJPEG/JPEG baseline
Video Resolution
Max support 3840×2160@30fps, 1080P@60fps
Video Bitrate
0.1~32Mbps
Video FPS
1-60 for 1080P and below, 4K@30fps
Streaming Protocols
SRT / HTTP / HLS / FLV / RTSP / RTMP(S) / UDP/RTP (Unicast/Multicast) ONVIF
Audio Encoding
---
Audio Format
AAC/AAC+/AAC++/MP3/MP2/AC3 G711
Sample Rates
8000/11250/22500/44100/48000Hz
Audio Channels
L/R Stereo
System
---
Control Method
Web based management – IP 192.168.1.169
Language
Chinese-English control interface
Firmware
Ethernet software upgrade
Working environment
---
Operating temperature
-10 to 70 deg C
Storage temperature
–20 to 80 deg C
Relative Humidity
5% to 90% non-condensing
Miscellaneous
---
Dimension (L× W× H)
23 (L) *250 (W) *3 (H) mm
Approx weight
1kg
Power adapter
AC input 12V 50/60Hz DC output 12V 8.5A
