Mine A5 LTE Bonding Streaming Camera

$885.00
  • 1/2.8 Inch Sony CMOS Sensor with 1.98mm focal length prime lens
  • Stream and record up to 4k @ 30fps
  • 3 Inch Touch Screen inferface
  • 4G LTE Bonding via 2 SIM Card Slots and WiFi
  • TF Card Slot (Max 256GB) for local recording
  • 3.5mm Stereo Input and Output
  • Micro HDMI Output
  • USB Type A for USB Ethernet Dongle
  • Browser & M Live app control
  • Add Logos, titles, timers
Add to Cart
Mine A5 LTE Bonding Streaming Camera
Mine A5 LTE Bonding Streaming Camera
Mine A5 LTE Bonding Streaming Camera
Mine A5 LTE Bonding Streaming Camera
Mine A5 LTE Bonding Streaming Camera
Mine A5 LTE Bonding Streaming Camera
Mine A5 LTE Bonding Streaming Camera
Product Details
Specifications
MineMedia A5 Specifications
  • Model
    Mine-A5
  • Name
    Network Bonding Streaming Camera
  • Sensor Type
    Sony CMOS
  • Sensor Size
    1/2.8 Inch
  • Effective Pixels
    8 Mega Pixels
  • Camera Angle
    Opposite Angle: 118.5 degrees; Horizontal 110.5 degrees; Vertical 76.3 degrees
  • Focal Length
    1.98mm
  • Lens Work Object Distance
    Prime Lens, 1m to infinity
  • Screen Size
    3 Inchs
  • Screen Characteristics
    Touchscreen
  • 4G Built-in
    Built-in 2x4G Sim Slots, LTE(FDD/TDD)
  • WiFi
    2.4G/5G
  • Streaming Protocol
    RTMP/RTMPS/SRT
  • Video Compression Standard
    H265/H264
  • Encoding Type
    H265 Main Profile/ H264 High,Main,Baseline
  • Maximum Resolution
    3840x2160P
  • FPS
    4K: 25/30 fps; 1080p: 25/30/50/60 fps
  • Bitrate
    Adjustable
  • Audio Compression Standard
    AAC
  • Audio Sampling Rate
    44.1K/48K
  • Audio Input
    Built in two channel microphone; 3.5mm Stereo
  • Audio Playback
    Built in speaker, 3.5mm Headphone
  • Storage
    TF Card(Max 256GB) slot
  • Video Format
    MP4 (H265/H264 + AAC)
  • File System Type
    FAT 32/ exFAT
  • M Live App Operating System
    Android/iOS
  • Charging Port
    USB Type C
  • Earphone Monitoring
    3.5mm
  • External Audio Input
    3.5mm
  • Video Output
    Micro HDMI
  • USB A
    External USB dongle/USB Network Card Option
  • Operating Temperature and Humidity
    0°C - 40°C, Humidity less than 95% (no condensation)
  • Power Supply
    DC 5V ± 10%, 8000mAh Battery Capacity (Built-in)
  • Maximum Power Consumtion
    8W
  • Dimensions
    130mm * 60mm * 80mm
  • Weight
    400g
